Question with Answer of ISRO 2006 Exam : Mechanical Engineering
01. In nodular iron , graphite is in the form of _________
Spheroids .
02. Hardness of steel depends on _________
amount of carbon it contains.
03. Tool high welding current in arc welding would result in _________
excessive spatter , under cutting along edges , irregular deposits , wasted electrodes .
 |
04. Which of the following processes would produce strongest components ?
Forging .
05.
05. Which of the following has maximum hardness ?
Martensite .
 |
06. The main advantage of line organization is its ________
- Effective command and control
- Defined responsibilities at all levels
- Rigid discipline in the organization
07. The mathematical technique for finding the best use of limited resources in an optimum manner is known as _________
Linear Programming .
The different types of linear programming are:
- Solving linear programming by Simplex method.
- Solving linear programming using R.
- Solving linear programming by graphical method.
- Solving linear programming with the use of an open solver.
08. Which of the following errors are generally distributed in accordance with the Gaussian distribution ?
Calibration Errors .
09. If the radius of wire strtchid by a load double , then it's young's modulus will _______
Young's modulus is material property not the geometric property .
10. Longitudinal stress in a thin cylinder subjected to internal pressure is _________
half of the hoop stress .
 |
11. If Poisson's ratio for a material is 0.5 , then the elastic modulus for the material is _______
3 times it's shear modulus .
12. Hydraulic testing of boiling is done at pressure __________
At 1.5 to 2 times the working pressure .
 |
13. 100 m of water column is equal to _______
100 KN/m2 .
14. Gantry girders are invariably designed to resist _________
Transverse and lateral loads .
15. A thin circular disc is rolling with a uniform linear speed , along a straight path on a plane surface . Consider the following statements in this regards .
The center of the disc has zero acceleration .
16. If a number of forces act on a rigid body , each force may be replaced by an equal and parallel force acting through a fixed point , together with a couple . For the rigid body to be in equilibrium _________
Both resultant force and couple must be zero .
17. Whirling speed of a shaft coincides with the natural frequency of its _________
Transverse vibration .
18. Which one of the following is not a friction clutch ?
Jaw clutch .
19. Pick-up the wrong statement . A flywheel ___
Controls the mean speed of rotation .
20. Purpose of using differential gear in automobile is to ________
help in turning .
