Simple Stresses in Machine Parts :
Compressive Stress and Strain :
Compressive Stress -
Where E is a constant of proportionality , which is known as young modulus or Modulus of elasticity . The unit of modulus of elasticity is GPa .
The machine parts are subjected to a various forces which is due to energy transmitted , weight of machine , frictional resistance , Inertia of reciprocating parts , change of temperature and lack of balance of moving parts .
Load :
Load is the external force acting upon a machine part .
- Dead or steady load
- Live or variable load
- Suddenly applied or Shock loads
- Impact load
Stress :
When external forces or loads act on a body , the internal stress resist the external forces . This internal force per unit area at section is known as unit stress or stress . Stress is denoted as ( sigma ) .The unit of stress is N/mm2 or Pascal ( Pa ) .
 |
Where -
P = Load acting on body .
A = Cross Section area .
Strain :
The ratio of change in length and original length of body is known as Strain . Strain is deformation of body when loads act on a body . Strain is denoted as ( epsilon ) . The unit of strain is unitless .
Where -
Tensile Stress and Strain :
Two equal and opposite axial pull ( tensile load ) is acting on a body then stress is known as tensile Stress . The ratio of increasing in length to original length is known as tensile strain .
Tensile Stress -
Tensile Strain -
Compressive Stress and Strain :
Two equal and opposite axial pushes ( Compressive load ) is acting on a body then stress is known as compressive Stress . The ratio of decreasing in length to original length is known as compressive strain .
Compressive Stress -
Compressive Strain -
Young's Modulus or Modulus of Elasticity :
According to Hooke's law , stress is directly proportional to Strain .
Where E is a constant of proportionality , which is known as young modulus or Modulus of elasticity . The unit of modulus of elasticity is GPa .
Shear Stresses in Machine Parts :
Two equal and opposite forces is acting on tangential section then stress is known as Shear Stress . Due to this stress , strain is called Shear Strain . Shear stress is denoted as tau and shear strain is denoted as phi .
Single Shearing , Rivet joining
Double Shearing , Rivet Joint
Shear Modulus or Modulus of Rigidity :
Experimentally found that the shear stress is directly proportional to shear strain .
Where C is constant of proportionality , which is known as Modulus of Rigidity . It is denoted as C , N , G .
